Canfield Connector offers a wide selection of quality electronic devices. We specialize in interconnection devices, electronic timers, proximity sensors, modules and specialty electronic devices.  Our DIN 43650 solenoid valve connectors are the core of Canfield Connector and come in MINI, ISO and Sub-Micro 8mm or 9.4mm sizes, and both hardwired or fully molded versions to fit your needs.





Molded DIN 43650 Solenoid Valve Connectors

Field Wire DIN 43650 Solenoid Valve Connectors

Male DIN 43650 Solenoid Valve Connectors & Accessories

Fieldbus Adapter DIN 43650 Solenoid Valve Connectors

CanGrip Wire Strain Relief Cord Grips

Tie Rod and Round Cylinder Proximity Sensors

Grooved Cylinder Proximity Sensors

All Threaded Magnetic Sensors

M8 Round Connectors

M12 Round Connectors

Double Ended Round Connectors

Timers and Electronics

Proportional Solenoid Drivers

Conveyor Controls

Condensate Drain Valves

Custom Assemblies

Sales Aids





Product Search
Name
Part Number
Functionality
Market


5K - Standard, Lighted, Suppressed, Non-Gasketed

The Canfield Connector Series 5K DIN solenoid valve connector all molded cord assembly offers a rugged one-piece design that is far better for environmental integrity than field wire solenoid valve connectors. Made from rugged yet flexible polyurethane, the connector housing boasts high durability factors and application versatility. The low profile "straight-line" interface/cord configuration allows for installation in many limited space applications. The Series 5K is different than the Series 5J version and is offered without the integrated gasket design in order to promote version compatibility as with the Canfield Connector Series MCCR and iLW. The Series 5K boasts an IP67/NEMA 6 rating when gasket is applied. The Series 5K as well as the Series 5F and Series 5J are the only molded valve connectors in the industry that feature a Hard Usage cord option in any length required, bi-directional indicator lights, and load suppression (not intended for UL 1449), and is Proudly Made in the U.S.A.

MORE...

5F - Standard, Lighted, Suppressed

The Canfield Series 5F all-molded DIN solenoid valve connector/gasket/cord assembly offers a completely molded design that is far better for environmental integrity than field wire versions. Made from rugged yet flexible polyurethane, the connector housing boasts high durability factors and application versatility. The low profile "straight-line" interface/cord configuration allows for installation in many limited space applications. The integrated gasket design boasts an IP67/NEMA 6 rating and makes it impossible to lose the gasket. The 5F and 5J are the only molded valve connectors in the industry that feature a HARD USAGE cord as a standard option in any length required, bi-directional indicator lights, and load suppression (not intended for UL 1449). UL and CSA versions are available as well. Canfield offers any version of the 5F connector with special wires including high flex, media compatible wire, special use wire, high temperature wire on request. The Series 5F is Proudly Made in the U.S.A.

MORE...

5J - Standard, Lighted, Suppressed

The Canfield Series 5J all-molded DIN solenoid valve connector/gasket/cord assembly offers a completely molded design that is far better for environmental integrity than field wire versions. Made from rugged yet flexible polyurethane, the connector housing boasts high durability factors and application versatility. The low profile "90°" interface/cord configuration allows for installation in many limited space applications. The integrated gasket design boasts an IP67/NEMA 6 rating and makes it impossible to lose the gasket. The 5J and 5F are the only molded valve connectors in the industry that feature a HARD USAGE cord as a standard option in any length required, bi-directional indicator lights, and load suppression (not intended for UL 1449). UL and CSA versions are available as well. Canfield offers any version of the 5J connector with special wires including high flex, media compatible wire, special use wire, high temperature wire on request. The Series 5J is Proudly Made in the U.S.A.

MORE...

5JGT - DIN to Deutsch Adapter

The GatorMate™ brand of electrical connectors from Canfield Connector are as tough as their name. This fully molded Deutsch, Amp, Delphi connector line exceeds expectation. The over-molded 5JD mobile hydraulic DIN 43650 Form "A" to Deutsch DT04-2P Adapter/connector solution is designed for use with hydraulic valves to facilitate connection to the DT06 mating connector. The connector is available with indicator lights and surge suppression and unlighted black or grey housing for "A" and "B" solenoids. All standard voltages are available and the housing is IP67 environment rated. The product is designed to adapt DIN 43650 Form "A" solenoid coils to the Deutsch connector found in many mobile hydraulic solenoid valve applications. Proudly made in the U.S.A.

MORE...

5FFAC - Fieldbus, Lighted, Suppressed

The Canfield Series 5FFAC all-molded DIN solenoid valve connector/gasket/cord offer a completely molded plug and play design that interfaces female ISO (DIN 43650 Form “A”), MINI and 9.4mm (Industry Standard) and 8mm Sub-Micro (DIN 43650 “C”) solenoid connections to 8mm or 12mm (round) circular connectors. Made from rugged yet flexible polyurethane, the connector housing boasts high durability factors and application versatility. The low profile “straight line” interface/cord configuration allows for installation in many limited space applications. The integrated gasket design boasts an IP67/NEMA 6 rating, is far better for environmental integrity than field wire versions and makes it impossible to lose the gasket! The 5FFAC and 5JFAC are the only molded valve connectors in the industry that feature bi-directional indicator lights and load suppression (not intended for UL 1449). UL and CSA versions are available as well. The Series 5FFAC is proudly Made in the U.S.A.

MORE...

5JFAC - Fieldbus, Lighted, Suppressed

The Canfield Series 5JFAC all-molded DIN solenoid valve connector/gasket/cord offer a completely molded plug and play design that interfaces female ISO (DIN 43650 Form “A”), MINI and 9.4mm (Industry Standard) and 8mm Sub-Micro (DIN 43650 “C”) solenoid connections to 8mm or 12mm (round) circular connectors as shown on the following pages. Made from rugged yet flexible polyurethane, the connector housing boasts high durability factors and application versatility. The low profile “straight line” interface/cord configuration allows for installation in many limited space applications. The integrated gasket design boasts an IP67/NEMA 6 rating, is far better for environmental integrity than field wire versions and makes it impossible to lose the gasket! The 5FFAC and 5JFAC are the only molded valve connectors in the industry that feature bi-directional indicator lights and load suppression (not intended for UL 1449). UL and CSA versions are available as well. The Series 5JFAC is proudly Made in the U.S.A.

MORE...

5FR - Rectified, Lighted, Suppressed

The Canfield Series 5FR solenoid valve connectors incorporate a full-wave bridge rectifier inside a fully molded connector. The 5FR converts alternating current to direct current reducing coil burnout due to valve sticking. Also, direct current eliminates AC "hum" inherent to alternating current. Made from rugged yet flexible polyurethane, the connector housing boasts high durability factors and application versatility. The low profile "straight-line" interface/cord configuration allows for installation in many limited space applications. The integrated gasket design boasts an IP67/NEMA 6 rating and makes it impossible to lose the gasket! Features bi-directional indicator lights, and load suppression (not intended for UL 1449). The Series 5FR is Proudly Made in the U.S.A.

MORE...

5JR - Rectified, Lighted, Suppressed

The Canfield Series 5JR solenoid valve connectors incorporate a full-wave bridge rectifier inside a fully molded connector. The 5JR converts alternating current to direct current reducing coil burnout due to valve sticking. Also, direct current eliminates AC "hum" inherent to alternating current. Made from rugged yet flexible polyurethane, the connector housing boasts high durability factors and application versatility. The low profile 90° interface/cord configuration allows for installation in many limited space applications. The integrated gasket design boasts an IP67/NEMA 6 rating and makes it impossible to lose the gasket! Features load suppression (not intended for UL 1449). The Series 5JR is Proudly Made in the U.S.A.

MORE...

5000 - Standard Hardwired

The ISO and 8mm Sub-Micro connectors are made according to DIN 43650 / ISO 4400, EN175301-803:2006. The MINI and 9.4mm Sub-Micro connectors are industry standards. All are used as protective enclosures for electrical connection in conjunction with hydraulic and pneumatic solenoid valves. These connectors offer distinct advantages over “hardwired” solenoid valves because of their modular design. Used where rapid installation and service are a must. Better than molded construction when special wire is needed or when using one long wire run.

MORE...

R5000 - Full Wave Bridge Rectifier

Canfield Connector’s R5000 Series solenoid valve connectors incorporate full-wave bridge rectifiers inside the DIN 43650 Form "A" / ISO 4400, EN175301-803:2006 connectors. This standard permits industry interchange-ability and has been embraced by the solenoid valve industry worldwide. The R5000 converts alternating current to direct current reducing coil burnout due to valve sticking. Also, direct current eliminates AC “hum” inherent to alternating current. Features include the ability for the user to wire the connector into existing installations. Wire connections are made inside the connector housing and the wire inlet is either PG9/PG11 strain relief, 1/2" conduit. The R5000 has a maximum current rating of 1 Amp continuous with maximum wire gauge diameter of 14 AWG. An indicator light is offered for instant diagnostics and to aid setup and installation.

MORE...

P5600 - Surge Suppression

The Micro Protective Connectors are available in standard MINI, DIN 43650 Form "A" / ISO 4400, EN175301-803:2006 and Sub-Micro 8mm and 9.4mm. The Canfield Connector MPCs provide electrical controllers surge suppression against voltage spikes caused by the solenoids used on hydraulic and pneumatic solenoid valves.

MORE...

DCP - DIN Coil Pin Protectors

The Canfield Connector DCP coil pin protectors are low cost replacements for solenoid connectors that ensure protection of solenoid terminals during shipping and handling. They can also be used to protect spade style terminals on a variety of other products. DCPs are available in a host of colors and styles as well as special logo markings to match the application. Constructed of low cost yet rugged polymers, the DCP adds aesthetic appeal and advertising value to the solenoid valve. There is a DCP available for ISO, industry standard MINI, Sub-Micro, and dual spade hydraulic coils.

MORE...

iLW - Interposed Lighted Wafer Indicator Light

The Canfield Connector Interposed Lighted Wafer is an electronic, state of the art lighting module designed to install between a DIN type coil and the mating connector. Utilizing SMT (Surface Mount Technology), the iLW’s ultra-thin design and high luminescence Gallium Arsenide LEDs enable the lighted wafer to retrofit existing applications or to be used in conjunction with unlighted connectors. Designed to “sandwich” between the connector and the coil, the iLW seals from dust and moisture. The iLW can be installed several times without degradation of the contact surfaces and is not polarity dependent.

MORE...

M5 - Male Quick Disconnect Interfaces

Canfield Connector male connectors are used as electrical quick disconnect interfaces for pneumatic and hydraulic valves and sensors. They are available in standard MINI, DIN 43650 Form "A" / ISO 4400, EN175301-803:2006, Sub-Micro 8mm, 9.4mm, and conduit arrangements. Some male connectors are available with 2+ ground or 3+ ground terminal options.

MORE...

MCCR - Multiple Control Distribution

The Canfield Connector MCCR is a cable distribution connector which uses pass-through technology to allow control of multiple parallel or independent devices. Devised with double solenoids and solenoid valve manifolds in mind, the MCCR allows for simplified wiring and easy replacement of components in an automated, modular environment. The gasket-thin head fits between a single female connector and the associated male device with the DIN 43650 Form "A", EN175301-803:2006 interface. Exiting from the MCCR head is a three conductor cable with ISO HT PG9 strain relief connector attached. Two available circuits allow for separate (independent) or parallel (simultaneous) control of the downstream device. The environment resistant quick connect style allows for plug and play designs in the factory that require modern hydraulic or pneumatic systems.

MORE...

FAC - 12mm to MINI, ISO, or Sub-Micro

The FAC series connectors are modular interface connectors made to conform to industry standard configurations. These connectors interface female ISO, MINI and Sub-Micro solenoid connections to industry standard male 7/8" (MINI) and 12mm (Micro) circular connectors. These are as shown on the following pages. These rugged modular connectors offer rapid installation and environmental protection designed to IP 65 and NEMA 4. Options include indication LED, surge suppression and various pre-wired circuit configurations to connect with popular multi-port electronic interconnection systems and field-bus systems.

MORE...

FAC - Automotive Standard to MINI or ISO

Canfield Connector FAC connectors are DIN 43650 Form A & C, Industry Standard Mini, and 9.4mm solenoid valve connectors that adapt connection from M12 and DIN 43650 Form A, Industry Standard Mini 7/8 Automotive standard inlet connectors. Made from the finest materials in the USA, these connectors mate with distribution boxes in a quick connect manner making assembly a snap. They are available in 3 or 5 Pin 7/8 Automotive, 4 or 5 Pin 12mm molded and wired, with or without indicator lights & surge suppression.

MORE...

Nylon Strain Relief Cord Grips

Canfield Connector’s Nylon Strain Relief CanGrip Connectors are a series of wire bulkhead feed through connectors which have integrated wire strain relief and sealing mechanism. These CanGrips are made from rugged engineered materials which are impervious to dust and moisture. Available in various NPT, PG, and metric thread sizes and in Gray or Black Nylon. These CanGrips are compatible with wire diameters from .079” to 1.732”, to ensure a tight fit while enhancing any wire installation.

MORE...

Nylon Flex Strain Relief Cord Grips

Canfield Connector’s Nylon Flex Strain Relief CanGrip Connectors are a series of wire bulkhead feed through connectors which have integrated wire strain relief and sealing mechanism. These CanGrips are made from rugged engineered materials which are impervious to dust and moisture. Available in various NPT, PG, and metric thread sizes and in Gray or Black Nylon. These CanGrips are compatible with wire diameters from .079” to .709” to ensure a tight fit while enhancing any wire installation.

MORE...

Nickel Strain Relief Cord Grips

Canfield Connector’s Nickel Plated Brass Strain Relief CanGrip Connectors are a series of wire bulkhead feed through connectors which have integrated wire strain relief and sealing mechanism. These CanGrips are made from rugged engineered materials which are impervious to dust and moisture. Available in various NPT, PG thread sizes. These CanGrips are compatible with wire diameters from .079” to 1.732” to ensure a tight fit while enhancing any wire installation.

MORE...

Stainless Steel Strain Relief

Canfield Connector’s Stainless Steel Strain Relief CanGrip Connectors are a series of wire bulkhead feed through connectors which have integrated wire strain relief and sealing mechanism. These CanGrips are made from rugged engineered materials which are impervious to dust and moisture. Available in various NPT, PG thread sizes. These CanGrips are compatible with wire diameters from .079” to 1.732” to ensure a tight fit while enhancing any wire installation.

MORE...

7000 - High Current

The Canfield Series 7000 proximity sensors are used to sense position on cylinders. They accommodate 2 to 8 inch bore tie rod cylinders or 3/4 to 4 inch round cylinders. This proven design is rugged yet cost effective. The Series 7000 boasts the largest number of custom circuits to match applications found in the market. Examples include; 1 or 4 Amp reed switches, normally open, normally closed or SPDT switch types, reed or electronic sensing elements in the same package style, and the industry’s first 120 VAC Hall sensor. Awide range of enclosures and connector options are available. To reduce stocking requirements, two clamp options feature a self-adjusting clamp for NFPA and other tie rod cylinders from 2 to 8 inch bore. Another clamp option features a band clamp from 3/4 to 4 inch round cylinders.

MORE...

7C - High Current

The Canfield Series 7C proximity sensors are used to sense position on pneumatic actuators equipped with magnetic pistons from 2" to 8" bore. This proven design is rugged yet cost effective. All switches feature a self-adjusting clamp that grips standard NFPA and custom cylinders eliminating stocking requirements of many clamps for different bore sizes. The Series 7C boasts the largest number of custom circuits to match applications found in the market. Examples include; 1 or 4 Amp reed switches, normally open, normally closed or SPDT switch types, reed or electronic sensing elements in the same package style, not to mention the industry’s first 120 VAC Hall sensor. The low cost 7C features a ½” conduit hub and wire lead to meet stringent electrical codes in certain regions and applications.

MORE...

7GL - General Location

The Canfield Connector 7GL is an expansion of the popular series 7000 “floating” clamp design, which adapts to NFPA tie rod linear actuators with 2 to 8 inch bore. this rugged magnetic proximity sensor can sense actuator position in stringent, general location applications. the switch features a robust, aircraft aluminum body, epoxy-filled, vibration and shock resistant, electronic circuit. Available in a normally open contact, the 7GL can switch current up to .5 Amps and has a voltage range of 0-120VAC/VDC 50/60 Hz.

MORE...

7HL - Hazardous Location

The Canfield Connector 7HL is a rugged magnetic proximity sensor designed to sense actuator position in stringent, hazardous location applications. The switch features a robust, epoxy-filled, aircraft aluminum body, and has a vibration and shock resistant, electronic circuit. The 7HL is an expansion of the popular Series 7000 “floating” clamp design and will clamp on 2 to 8 inch bore NFPA tie rod linear actuators. This product is designed to operate in hazardous locations, this switch is CSA approved for Class I, Division 2, Groups A, B, C, and D; Class II, Division 2, Groups F and G; and Class III.

MORE...

8000 - Low Current

The Canfield Connector Series 8000 Reed and Electronic sensors are compact units designed for sensing applications on round cylinders from 9/16" - 4" and tie-rod pneumatic cylinders from 3/4" - 8" bore. These sensors offer a wide voltage range from 0-120 VAC/VDC 50/60 Hz and high current capacity up to 0.5 Amps. They include high intensity indicator lights and a wide viewing angle. The sensor's small package can fit easily on the smallest cylinder without appearing too large. The Series 8000's design promotes ease of installation with a tight fit. Options include 9ft. PVC or 8mm quick connect male pigtail.

MORE...

8WF - Weld Field Immune

The Canfield Connector Series 8WF weld field immune electronic sensors are compact magnetic sensors designed for sensing position magnetic pistons on pneumatic actuators while ignoring electro-magnetic pulses generated from AC weld fields. Designed for round type cylinders with diameters from 9/16" - 4" and tie-rod type cylinders from 3/4" - 8" bore, the 8WF features a rugged stainless steel and nylon enclosure and high current capacity up to 0.2 Amps and 24VDC input. Included in the sensor is a high intensity indicator light that can be seen from a wide viewing angle. The sensor's small package can fit easily on the smallest cylinder without appearing too large. The Series 8WF design promotes ease of installation with a tight fit. Options include 9ft. PVC or 8mm quick connect male pigtail.

MORE...

8WS - Dovetail Groove (Numatics Grooves)

The Canfield Connector Series 8WS reed and electronic magnet sensors are rugged yet compact switches used to sense position on pneumatic actuators equipped with a magnetic piston and 12mm dovetail groove. The switch can be slipped in and tightened from anywhere along the groove that is fabricated into the cylinder wall or clamping system. The switch features a die cast holder which clamps to the cylinder groove while the electronics are fully encapsulated and resistance to environment. These sensors offer a wide voltage range from 0-120 V AC/DC 50/60Hz and have a up to a 500 mA switching current rating. The switch has a high intensity indicator light which indicates power to the switch and load. The switch comes standard with 9 ft. PVC or 8mm quick connect male pigtail. Fits: Numatics cylinder grooves

MORE...

9D - Dovetail Groove (Fabco, Numatics, Rotomation)

The Canfield Connector Series 9D is a universal, ultra-small, magnetic proximity switch available in both solid state electronic and reed styles. These sensors are designed to fit the most stringent space requirements by use of a standard .250 inch dovetail slot. Many other mounting options are also available. The electronic sensor exhibits greater sensitivity to magnetism with reduced dead-band and hysteresis as compared to competitive devices. The reed sensor offers a wide operating voltage range. The molded switch has an on board indicator light that can be viewed from wide angles. Standard connection to the sensor is provided by a 9 ft. PVC or 8mm quick connect male pigtail. The rugged, fully encapsulated switch is shipped with mounting hardware ready for installation. Fits: Fabco, Numatics, Rotomation cylinder grooves

MORE...

9E - Dovetail Groove (Fabco, Numatics, Rotomation)

The Canfield Connector Series 9E is a universal, ultra-small, magnetic proximity switch available in both solid state electronic and reed styles. These sensors are designed to fit the most stringent space requirements by use of a standard .250 inch dovetail slot. Many other mounting options are also available. The electronic sensor exhibits greater sensitivity to magnetism with reduced dead-band and hysteresis as compared to competitive devices. The reed sensor offers a wide operating voltage range. The molded switch has an on board indicator light that can be viewed from wide angles. Standard connection to the sensor is provided by a 9 ft. PVC or 8mm quick connect male pigtail. The rugged, fully encapsulated switch is shipped with mounting hardware ready for installation. Fits: Fabco, Numatics, Rotomation cylinder grooves

MORE...

8F - Round Groove (Wika)

The Canfield Connector Series 8F is a compact yet rugged magnetic reed type proximity sensor designed for rigorous applications where critical magnetic sensing is needed. The tough nylon shell is over-molded with polyurethane to create an environmentally resilient seal from the elements and is rated to IP67. The compact size and cylindrical shape are ideal for mounting in a simple hole or cylindrical shape. There is a tab mounting version also available. The 8F can be mounted solidly and fit into many common magnetic sensing applications. Offered standard with 9ft. cord or an M8 quick connect connector, the switch is also available in either normally open or normally closed switch types. Fits: Wika cylinder grooves

MORE...

9C - Round Groove (Bimba, Compact Air, DE-STA-CO, Robohand, SMC)

The Series 9C is a compact, universal, magnetically operated proximity switch commonly used on aluminum extruded profile type linear actuators equipped with magnetic pistons. The switches are available in both reed and electronic styles and made to fit into a 4mm key hole type slot. Position fixing is accomplished by means of a screw that is supplied in the switch body. The on board indicator light shows instant switch diagnostics to minimize downtime and facilitate installation and can be seen from wide angles. Available in the standard 9 ft. PVC wired or optional 8mm quick connect, the switch can handle AC or DC current in several configurations. The 9C is assembled in engineered polymers and designed to meet NEMA 6 / IP 67 environmental specifications. Fits: Bimba, Compact Air, DE-STA-CO, Robohand, SMC cylinder grooves

MORE...

9M50 - Round Groove (Norgren)

The Canfield Connector 9M50 is a compact full featured magnetic proximity switch designed to fit a “D” shaped groove detail designed into linear actuators. The innovative design allows the switch to be inserted anywhere along the linear actuator and then rotated and locked into position. When installed the switch lies flat against the cylinder housing and does not protrude beyond the cylinder face making installations neat and clean. The fully encapsulated switch is offered in reed, and electronic styles in either NPN or PNP. The robust epoxy encapsulated design meets IP67, NEMA 6 environmental protection. Voltage ranges are available from 5 to 120 VAC/DC in multiple versions. Maximum current draw is 200 mA. Standard connection is provided by a 9 ft. PVC or 8mm quick connect male pigtail. Fits: Norgren cylinder grooves

MORE...

9N - Round Groove (SMC)

The Canfield Connector 9N is a right angle version of the popular 4.25mm round groove type switches commonly used in aluminum extrusion type linear actuators. The 9N features reed or electronic versions and are available in standard 9 ft. PVC or 8mm quick connect male pigtail. The 9N is IP-67 which makes it dust tight and water resistant. Fits: SMC cylinder grooves

MORE...

9K - U Groove (Mindman, Koganei)

The Canfield Connector Series 9K is a profile mounting type switch that fits in a 4.2mm "U" groove which normally is designed into an aluminum extrusion type linear actuator. Available in reed or electronic versions, the 9K is also available with a 9 ft. PVC or 8mm quick connect male pigtail. The switch is IP67 which is dust tight and water resistant. Fits: Mindman, Koganei cylinder grooves

MORE...

9Q - T-Slot Groove (Parker)

The Canfield Connector Series 9Q is a magnetic proximity switch that is engineered to fit into extruded actuators that are made with a “T” slot. The unique design of the 9Q enables it to be installed anywhere along the slot and assembled in place without taking off the actuator end-cap. The rugged polyurethane encapsulated switch features an innovative design that incorporates a hard nylon shell. The switches are available in reed or electronic sensing and feature surge suppression and on board indicator light standard. Offered as a flying lead or 8mm quick connect, the sensors are quickly and easily wired in to any application. The sensors meet NEMA 6 / IP67 environmental specifications and are corrosion and wash-down compatible. This sensor is proudly made in the USA. Fits: Parker cylinder grooves

MORE...

9T - T-Slot Groove (SMC)

The Canfield Connector Series 9T is a compact yet robust switch used to sense position of magnetic pistons designed into aluminum extrusion type linear actuators. The 9T fits a 7.2mm X 3.9mm rectangular groove which is designed into the actuator body. Available in reed or electronic versions, the 9T features standard 9 ft. PVC or 8mm quick connect male pigtail, and are rated IP-67 against the ingress of dust and water. Fits: SMC cylinder grooves

MORE...

9F - T-Slot Groove (Fabco, Festo, Numatics, Rotomation)

The Canfield Connector Series 9F is a universal, ultra-small, magnetic proximity switch available in both solid state electronic and reed styles. These sensors are designed to fit the most stringent space requirements by using a 4mm "T" slot. The electronic sensor exhibits greater sensitivity to magnetism with reduced dead-band and hysteresis as compared to competitive devices. The reed sensor offers a wide operating voltage range. The molded switch has an on board indicator light that can be viewed from wide angles. Standard connection to the sensor is provided by a 9 ft. PVC or 8mm quick connect male pigtail. The rugged, fully encapsulated switch is shipped with mounting hardware ready for installation. Fits: Fabco, Festo, Numatics, Rotomation cylinder grooves

MORE...

9G - T-Slot Groove (Fabco, Numatics, Rotomation)

The Canfield Connector 9G linear magnetic position sensor is designed to work with aluminum extrusion type actuators that have a 6.2mm X 4.4mm rectangular groove designed into the body. Available in reed or electronic versions, the 9G fits into commonly used sensor grooves. Standard connection to the sensor is provided by a 9 ft. PVC or 8mm quick connect male pigtail. The switch is water resistant and dust tight to IP67. Fits: Fabco, Numatics, Rotomation cylinder grooves

MORE...

9H - T-Slot Groove (4x4)

The Canfield Connector Series 9H is a profile mounting type switch that fits in a 4mm X 4mm square groove which normally is designed into an aluminum extrusion type linear actuator. Available in reed or electronic versions, the 9H is also available with a 9 ft. PVC or 8mm quick connect male pigtail. The switch is IP67 which is dust tight and water resistant. Fits: 4x4 cylinder grooves

MORE...

CS - All Threaded Magnetic Sensor for Universal Applications

The Canfield Connector Series CS Cylindrical Threaded Mount Sensor is a rugged and compact magnetic sensor set within a miniature encapsulated Stainless Steel M8 threaded housing. Available in reed or electronic sensing, the CS sensor can sense magnets or magnetic objects in industrial machinery and mobile equipment. Typically used where greater sensing distance is required, the CS sensor changes state in the presence of a magnetic field. Electrical output for the CS is normally open, with sinking or sourcing outputs for the electronic versions. Input voltages available are 0 to 120 VAC/DC .5 Amp maximum for the reed and 5-24 VDC 0.2 Amp maximum for the electronic versions. The sensor is made of a Stainless Steel body, TPU encapsulant and has PVC wire standard and is NEMA 6. Temperature ranges are -20° to 80°C. The CS Series is proudly made in the U.S.A.

MORE...

5800 - DIN Micro Logic Timer

The Canfield Connector micro logic timer is a solid state electronic timing unit incorporated inside the standard MINI and DIN 43650 Form "A" / ISO 4400, EN 175301-803:2000 electrical connectors. The MLT allows precise timing and logic functions in a small, easily mounted enclosure. there are eight standard timer types. Each timer incorporates circuitry for AC or DC operation with a wide voltage range.

MORE...

MBT - 12 Functions in 1 Multifunction Block Timer

The Canfield Connector model MBT Multifunction Block Timer is designed as a full featured multiple mode of operation, multiple voltage, all-in-one timer. The unit is offered in a small epoxy encapsulated housing with on board mode switches and adjustments. The unit has a time range adjustable from 0.1 seconds to 33.3 hours. Features include twelve modes of operation including a multitude of logic function possibilities and an indicator light for fast troubleshooting. The unit can be used to trigger another MBT in a cascade type arrangement, to meet complex functions or longer time ranges. With a voltage range of 12-240 VDC / 24-240 VAC 50/60 Hz, the MBT can instantly handle all mobile, industrial and automation applications right off the shelf. Each timer is 100% tested for function and quality and is resistant to dust, vibration and humidity. Mounting is accomplished by use of a through hole able to accommodate up to a 6mm diameter screw. Electrical connections are .250" AMP Fasten posts for crimp type push-on connectors.

MORE...

Sandwich CRT - Condensation Removal Timer

This Canfield Connector miniature timer makes any valve, with the DIN 43650 Form “A”/ISO 4400, EN175301-803:2000 electrical interface, able to operate as a compressed air system condensate removal valve. The unit installs in a modular form between an existing coil and connector. No new wiring is necessary. Retrofits on virtually any installation. It works with the valve brand of your choice. The cycle and on times are easily adjustable and two indicator lights show status.

MORE...

TMLT - Solid State Micrologic Timer Module

The Canfield Connector TMLT is an ultra-compact all solid state timer incorporated into a vibration and environment resistant composite encapsulant housing. The heart of the timer is a powerful microprocessor that is made in quantity then programmed to become the timer type according to customer specification. Featuring 6 timer modes of operation with two voltage ranges; 12-240V AC/DC or 12-60 VDC and four output options; Sinking ON First, Sinking OFF First, Sourcing ON First, and Sourcing OFF First, and 13 time ranges, from 0.1 to 2000 seconds. The timer is available with screwdriver or hand adjustment, and troubleshooting is a breeze with the on board indicator light. The TMLT is versatile as well as rugged, and each timer is 100% tested, made in America and resistant to dust, vibration and humidity. Mounting is accomplished by use of a through hole able to accommodate up to a 1/4" (6mm) screw or by use of a DIN rail mount adapter plate. Electrical connections are .250" AMP Faston posts for crimp type push-on connectors.

MORE...

5950 - Micro Proportional Driver

A Micro Proportional Driver provides accurate control of hydraulic and pneumatic proportional solenoid valves used in mobile construction equipment and industrial processes. The MPD can control the flow of air or liquid linearly at a setting from 0.10-20 seconds. One example of use would be in a paint system. The MPD allows a solenoid to oscillate, significantly reducing system shock and wear commonly found in non-oscillation digital valve systems. The micro proportional driver is a compact electronic circuit built into an environment-resistant miniaturized enclosure. the circuit features control of proportional solenoids and operators. Functions include minimum and maximum current limiting, control signals from 0-10V or 0-20 mA (with a step function at 0.2V or 0.4 mA included for minimum current), a 0.1-20 sec. linear ramp up/ramp down adjustment and output current proportional to input command signal. This unit incorporates the DIN 43650 Form "A" / ISO 4400, EN175301-803:2000 connector male and female interface. The unit is mounted by use of a single mounting screw, DIN connector and two gaskets. Built to meet NEMA 4 environment standards, the MPD is made from engineered polymers for resistance to harsh chemicals and ingress of water or foreign substances. adjustments are made on the top surface of the unit. the unit can control any proportional solenoid valve operation within the values specified below using variable pulse width modulation.

MORE...

B5950 - Block Micro Proportional Driver

The Canfield Connector Series B5950 is a rugged proportional driver built into an epoxy potted enclosure designed to control linear proportional solenoid operators. Features include selectable control signal inputs from 0-5V or 0-20 mA with adjustable min/max current output. The output steps to the minimum current setting when 0.1V or 0.4 mA is applied to the control signal input. Also included in the compact package is a 0.1 to 20 second adjustable ramp-up and ramp-down output and sine wave dithering (PWM) with adjustable amplitude and frequency. The B5950 has an output current that is proportional to the command signal input. Assembly and mounting of the unit is accomplished by use of a 6mm diameter mounting hole in the body of the unit. Connection is made by use of a miniature header strip which accommodates stranded or solid wire to 3mm diameter. Adjustments are easily accessible on the top surface of the unit. Additional features include on-board diagnostics such as a red indicator light for power and a yellow indicator light for output to the solenoid. The B5950 can be used to control any solenoid operator designed to meet the technical specifications as shown on this brochure.

MORE...

D5400 - Micro Solenoid Driver Power Converter

The Canfield Connector Series D5400 Micro Solenoid Driver is a NEMA 4 DIN 43650 Form "A" / ISO 4400, EN175301-803:2000 and MINI type connector with a built in electronic circuit used to induce solenoid pull-in and reduce holding current. The time proven MSD has been designed into many applications where heat buildup occurs which reduces operating efficiency and life span of solenoid valves. The MSD has two main functions: one is to induce faster or stronger than usual response times at solenoid pull-in, the second is to reduce the net wattage of the solenoid during hold-in. The MSD drives the coil with a high input voltage for a fixed time period until the coil has shifted at which time the MSD reduces the holding voltage, which saves power, and the solenoid runs cool. The MSD is often used to replace low voltage power supplies where a 24 VDC solenoid valve can then be operated by 120 VAC. The Alternating current is rectified and the duty cycle reduced so as to operate the valve at proper voltage and wattage ranges. An additional advantage can be found when the MSD drops the holding voltage, which then reduces heat and current requirements.

MORE...

5FMSD - In-line Micro Solenoid Driver Molded Connector

The Canfield Connector Series 5FMSD is a solenoid driver circuit (Coil Saver) tucked away in our all new in-line electronics package coupled with our 5F all-molded DIN solenoid valve connector/gasket/cord assembly for DIN 43650 Form A, Industry and Form C Solenoid Valve Connectors (EN 175301-803-2000 ). The integrated gasket design boasts an IP67/NEMA 6 rating and makes it impossible to lose the gasket. Made from rugged yet flexible polyurethane, the connector housing boasts high durability factors and application versatility. The Coil Saver enhances solenoid valve function as it lowers the wattage of solenoid operators of solenoid valves as it first applies a full voltage to ensure strong pull-in then drops the current when the solenoid magnetic circuit is most efficient and lowers wattage during long term energization or repeated cycles and lower RMS wattage. Both the in-line Coil Saver package and the 5F are fully encapsulated enclosures. This design allows for the Coil Saver to be isolated from the heat of the solenoid as well as installed upstream, away from the coil connector that is designed for this heat. The DC voltage version is 46mm by 15mm cylinder and is IP68 fully sealed from dust and water ingress. The in-line package can control input DC voltage and supplies PWM DC to the coil. The low profile "straight-line" interface/cord configuration allows for installation in many limited space applications The Series 5FMSD is Proudly Made in the U.S.A.

MORE...

5JMSD - In-line Micro Solenoid Driver Molded Connectors

The Canfield Connector Series 5JMSD is a solenoid driver circuit (Coil Saver) tucked away in our all new in-line electronics package coupled with our 5J all-molded DIN solenoid valve connector/gasket/cord assembly for DIN 43650 Form A, Industry and Form C Solenoid Valve Connectors (EN 175301-803-2000 ). The integrated gasket design boasts an IP67/NEMA 6 rating and makes it impossible to lose the gasket. Made from rugged yet flexible polyurethane, the connector housing boasts high durability factors and application versatility. The Coil Saver enhances solenoid valve function as it lowers the wattage of solenoid operators of solenoid valves as it first applies a full voltage to ensure strong pull-in then drops the current when the solenoid magnetic circuit is most efficient and lowers wattage during long term energization or repeated cycles and lower RMS wattage. Both the in-line Coil Saver package and the 5J are fully encapsulated enclosures. This design allows for the Coil Saver to be isolated from the heat of the solenoid as well as installed upstream, away from the coil connector that is designed for this heat. The DC voltage version is 46mm by 15mm cylinder and is IP68 fully sealed from dust and water ingress. The in-line package can control input DC voltage and supplies PWM DC to the coil. The Series 5JMSD is Proudly Made in the U.S.A.

MORE...

8mm Female Molded Locking

M8, 8mm Female Molded Locking Euro-style solenoid and sensor round connectors feature metric locking, and are used for factory automation, commercial electronics, process control, and industrial instrumentation. Available in 3 pin or 4 pin, 120V AC/DC, 4 Amps max.

MORE...

8mm Female Field Wireable

M8, 8mm Female Field Wireable Euro-style solenoid and sensor round connectors feature metric locking, and are used for factory automation, commercial electronics, process control, and industrial instrumentation. Available in 3 pin, 120V AC/DC, 4 Amps max.

MORE...

8mm Male Field Wireable

M8, 8mm Male Field Wireable Euro-style solenoid and sensor round connectors feature metric locking, and are used for factory automation, commercial electronics, process control, and industrial instrumentation. Available in 3 pin, 120V AC/DC, 4 Amps max.

MORE...

12mm Female Molded Locking

M12, 12mm Female Molded Locking Euro-style solenoid and sensor round connectors feature metric locking, and are used for factory automation, commercial electronics, process control, and industrial instrumentation. Available in 3 pin, 250V AC/DC, 4 Amps max.

MORE...

12mm Female Field Wireable

M12, 12mm Female Field Wireable Euro-style solenoid and sensor round connectors feature metric locking, and are used for factory automation, commercial electronics, process control, and industrial instrumentation. Available in 4 pin, 250V AC/DC, 3 Amps max.

MORE...

12mm Male Field Wireable

M12, 12mm Male Field Wireable Euro-style solenoid and sensor round connectors feature metric locking, and are used for factory automation, commercial electronics, process control, and industrial instrumentation. Available in 4 pin, 250V AC/DC, 3 Amps max.

MORE...

12mm Male x 12mm Female Molded Locking

Fully molded 12mm Male Molded Locking Cable round connector to 12mm Female Molded Locking Cable round connector, used for factory automation, commercial electronics, process control, and industrial instrumentation. Available in 4 pin, 250V AC/DC, 4 Amps max.

MORE...

12mm Male x 8mm Female Molded Locking

Fully molded 12mm Male Molded Locking Cable round connector to 8mm Female Molded Locking Cable round connector, used for factory automation, commercial electronics, process control, and industrial instrumentation. Available in 3 pin, 120V AC/DC, 4 Amps max.

MORE...

OSV - Optical Sensor Valve

Canfield Connector’s OSV Conveyor Control Photo eye/solenoid valve combination and is designed to be used as a sensing and pneumatic output device in one The OSV is mounted on Live Roller Conveyor type equipment and features a low cost yet robust design that facilitates easy installation as well as reliable function by use of polarized retro-reflective photo-eye on board. The photo-eyes is made up of an infra-red emitting LED that shines through polarity filters so as to enable the OSV to filter out ambient light and ignore flashers and nominally direct sunlight. The sensor has an internal time delay which prevents slowing of the product on the conveyor as well as top and bottom showing indicator lights which show sensor condition. The solenoid valve comes with a spring compensated plunger seat design which is designed for 20 million cycles in clean-dry air. OSV can be used in singulation or slug discharge mode dependent on the control desired. The Canfield Connector OSV is designed for reliable sensing of objects moving through conveyor zones in order to maximize product flow while preventing product damage.

MORE...

CRDV - Condensation Removal Drain Valve

The Series CRDV (Condensation Removal Drain Valve) is a unique and efficient way to keep your air lines and tanks free of water with this robust electronic timed automatic drain valve. The unit installs in a modular form between an existing coil and connector with a plug and play design and retrofits on virtually any installation. The Cycle and On times are easily adjustable on the compact sandwich timer and features two status indicator lights. The Cycle Time drain has settings to release moisture every 1 to 45 minutes. The On Time setting allows you to set how long you want the valve open, 0.25 to 25 seconds. We offer a variety of Nylon or Brass valves depending on your application. These 2-Way, 2-Position, Normally Closed valves range from 1/4”, 3/8”, 1/2” or 1” NPT and can handle pressures up to 230 psi max. The Series CRDV offers its users the most versatile combination of timing and flow capacities in the industry today, and is proudly made in the USA.

MORE...

CRDVS - Closed Loop Demand Drain Valve

The Series CRDV/S Condensate Removal Drain Valve keeps your air compressor tank and air lines free of moisture by coupling a state of the art automatic timer with a solenoid valve, reducing rust and clogged air components while increasing compressor cycling and machine life. It features a self-cleaning cycle every 24 hours, status indicator lights, environment resistant design for long cycle life, along with an on board microprocessor from discrete components. As water effluent enters the CRDV/S, the self-learning mode opens the valve more often or less often based on the sensing of the water and demand thereof. The utility, size, ease of installation and price rival the features and cost of conventional timed electric drains.

MORE...

OEM Molded Connectors

At Canfield Connector we are specialists in production of both male and female connectors used in industrial, commercial machinery and mobile applications. From standardized connections such as 8mm four pin round connectors to special connectors used on cell towers, Canfield can make a connector for your demanding application. Many connectors are over molded for environmental compliance and are practically indestructible having up to an IP67 rating for dust and water ingress. Only premium materials in contact and housings are used. At Canfield we invite your special connector applications.

MORE...

CAN-SAK Point of Purchase Rack

The CAN-SAK point of purchase display features a popular variety of individually bagged, 5J fully molded connectors which mate to your standard solenoid valves. The three tier 360° rotating 5 Ft. display rack along with the individually packaged clear hanging bag allows for easy vision to see what your buying. Easy markings on bags and boxes help identify the product to fit your needs. The product sells itself! Grab and Go!

MORE...

Sample Case

The Canfield Connector Sample Case is a convenient way to acquire a representative sampling from among our full line of products in one efficient package. Use them as product displays. Let your customers touch, feel and examine them up close to see the Canfield Connector difference for themselves. Order the complete set of Connectors, Sensors, Timers and our most recent catalogs and brochures, or request them as individual trays of components.

MORE...
